Description
Technical parameters of w series piston air compressor
| Model | Exhaust pressure (mpa) |
Capacity (m³/min) |
Cylinder (Diamm*Qty) |
Diesel engine/motor (kw/hp) |
Dimension (cm) |
Weight (kg) |
||
| l | w | h | ||||||
| W-1.8/5 | 0.5 | 1.8 | 100*3 | S1100 | 140 | 70 | 100 | 320 |
| W-2/5 | 0.5 | 2 | 115*3 | S1100 | 165 | 81 | 105 | 450 |
| W-2.6/5 | 0.5 | 2.6 | 115*3 | S1110 | 165 | 81 | 105 | 490 |
| W-2.8/5 | 0.5 | 2.8 | 115*3 | S1115 | 178 | 87 | 124 | 550 |
| W-2.8/5-GD | 0.5 | 2.8 | 115*3 | 15KW/20HP | 178 | 87 | 124 | 550 |
| W-3/5 | 0.5 | 3 | 125*3 | S1115 | 180 | 90 | 130 | 600 |
| 2V-3.5/5 | 0.5 | 3.5 | 115*4 | S1125 | 180 | 95 | 130 | 650 |
| 2V-3.5/5-D | 0.5 | 3.5 | 115*3 | 18.5KW/25HP | 180 | 95 | 130 | 650 |
| 2V-4/5 | 0.5 | 4 | 120*4 | S1125 | 180 | 95 | 130 | 700 |
| 2V-4/5-D | 0.5 | 4 | 120*4 | 18.5KW/25HP 22KW/30HP | 180 | 95 | 130 | 700 |
| W-1.8/7 | 0.7 | 1.8 | 100*3 | S1100 | 165 | 81 | 105 | 450 |
| W-1.8/7-D | 0.7 | 1.8 | 100*3 | 11KW/15HP | 165 | 81 | 105 | 450 |
| W-2.6/7 | 0.7 | 2.6 | 125*3 | S1115 | 178 | 87 | 124 | 480 |
| W-2.6/7-D | 0.7 | 2.6 | 125*3 | 15KW/20HP | 178 | 87 | 124 | 480 |
| W-3.2/7 | 0.7 | 3.2 | 125*3 | S1125 | 196 | 90 | 125 | 550 |
| W-3.2/7-D | 0.7 | 3.2 | 125*3 | 18.5KW/25HP | 196 | 90 | 125 | 550 |
| W-3.2/7-ZD | 0.7 | 3.2 | 125*3 | 18.5KW/25HP | 196 | 90 | 125 | 550 |
